Fully Automatic Rotary Microtome

LOREAX Precise Fully Automatic Rotary Microtome Has A Motor Operated Hand Wheel With Variable Speed Control To Ensure The Ease of Sectioning Where As The Variety Of Spicemen Has A Different Hardness.

Technical Specification

Model	LMT- FAM670
Operation	Fully Automatic.
Section Thickness Range:	1µm To 100 µm. (In Increment Of 1µm)
Trimming Thickness Range.	1µm To 600 µm. (In Increment Of 1µm)
Specimen Retraction Setting Range.	1µm To 200 µm. (In Increment Of 1µm)
Specimen Orientation.	8 X,Y Axis, 360 Around Z Axis
Vertical Stroke.	70 mm
Horizontal Advancement:	25 mm
Sectioning Mode.	Five Mode Of Sectioning.
Dimension. (L X W X H)	480mm x 390mm x 280mm.
Weight:	36 kg (approx)

Your Work, Our Responsibility

■ High Precision Motorizes Specimen Advancement System.
■ Colour Touch Enable Control Panel.
■ Counter Weight Balanced Hand Wheel And Ergonomically Located Hand Wheel Lock.
■ Acoustic Or Acrostic Signal Of Specimen Feed At End And Home Position.
■ Lateral Displacement Of Blade Holder To Ensure The Use Of entire length of blade.
■ Low And High Profile Compatible Blade Holder.
■ Blade Holder With Integrated Finger Protect Guard And Blade Ejector.
■ Spacious Waste Tray With Arm Rest.
